R2000 Multi-tags Middle Range UHF RFID Reader 0-6M
Feature
- Built in the RFID module of R2000
- The stable reading distance could reach 8M
- Multiple tags reading ability
- High sensitivity to tag
- Support RSSI indication
- Waterproof and sunscreen
- Support SDK dynamic link libraries(DLL) and secondary development
Item No. | |
DO-9282A | RS232,RS485 |
DO-9282B | RS232,TCP/IP |
DO-9282W | RS232,WIFI |
| DO-9282G | RS232,GPRS （4G） |
Performance Parameters | |
Working Frequency | 902~928 MHz or 865~868MHz |
Protocol | ISO18000-6C(EPC C1 GEN2) |
Chip | Impinj R2000 |
RF power | 0～30dBm(Adjustable) |
Software & SDK | DEMO and C#, VC , Java |
Industrial lightning protection | 6000V |
Low temperature protection | Northeast, Northwest extremely cold region, low temperature protection |
Reading range | stable reading range 8M(Depends on tag & environment) |
Tag handling volume | 0-200 tags |
Storage space | 1M or 8M Flash save without power supply(customized) |
Real-time clock | without power supply, real-time clock save and working(customized) |
Frequency modulation | hopping or fixed frequency |
Input/output port | Two-way relay output(customized), two-way I/O input(customized) |
RSSI | RSSI numerical test |
Antenna gain | 8dBi circular polarization |
Working way | Buzzer & LED |
Power | 12V/3A Adaptor |
Ethernet power supply | POE(customized) |
Physical Parameters | |
Item size | 220x220x50mm |
Package size | 410x270x110mm |
Net weight | 3KG |
Shell material | ABS |
Working temperature | -20℃~+65℃ |
Storage temperature | -45℃~+95℃ |
