Raspberry PI RFID 4 Chanel UHF long range RFID reader
It is very simple RFID hardware for developing ,can be speed up much time of project implementation , easy multi-readers in same system in different points,visual reader working states data collectionFeatures
- Raspberry OS based on Linux OS carrying ARM CPU keeps working without crash.
- Impinj R2000 chip and double power amplifier synthetic circuit.
- Programming language support python, JAVA and so on.
- Interfaces support Bluetooth, WIFI wireless methods extensible, keyboard mouse supportable.
- Easier equipment deployment, networking building, faster for projects carrying out successfully.
Application:
- Transportation vehicle management: Monitor and manage the transportation of vehicle and container
- Custom management: custom clearance and transit of material
- Logistic management: manage the flow of commodity, mail and package
- Manufacturing sequence: monitor parts during the whole productive process
- Device management: monitor the flow of device
Specification
| Performance parameters | |
|---|---|
| Working Frequency | 902~928 MHz or 865~868MHz |
| Protocol | ISO18000-6C(EPC C1 GEN2) |
| RF power | 0~30dBm(Adjustable) |
| Software & SDK | Demo software; API; Development Guide; User manual |
| Interfaces | RS-232 serial port, RS-485,RJ-45, TCP/IP,RTC,Wiegand 26 34 66,USB2.0 |
| Reading range | stable reading range 12M(Depends on tag & environment) |
| Channel bandwidth | ＜200KHz |
| Low temperature protection | Northeast, Northwest extremely cold region, low temperature protection |
| Frequency stability | ≤±10ppm |
| Input/output port | 4 opt coupler input/ 4 relay output |
| External antenna | 4x 9dBi /6dBi /12dBi RFID antenna/ Bluetooth antenna optional |
| Working way | Buzzer |
| Power | 12V/3A Adaptor |
| Physical parameters: | |
| Item size | 256mm×148mm×43.5mm |
| Antenna interface | 4×TNC interface |
| Net weight | 1.36Kgs |
| Shell material | Casting Aluminum |
| Working temperature | -20℃~+65℃ |
| Storage temperature | -45℃~+95℃ |
