RFID Windshield tag
The RFID Windshield tag is designed to be attached to optimization design of automobile glass. It meets EPC Global C1G2 as well as ISO/IEC 18000-6C. It has a unique ID and can store additional information.Features
- Long Read Range: average reading distance reach up to 4m
- Strong 3M adhesive
- Stable performance
- Waterproof surface material
Description
The UHF RFID Windshield Tags EPC Global C1G2 as well as ISO/IEC 18000-6C,it offer a more accurate and secure way to allow access into various locations like a gated community, company/corporate secured parking solution. The inlay ues passive RFID chip and RFID antenna and they sealed between thin layers of polypropylene,one side can be printed . The RFID Windshield Tag uses passive RFID UHF technology offering a more economical option and long read distance to the active windshield tags available. A tamper-evident option placed slits in the label and adhesive layers what is good desgin for unique identifiation.
It can be directly stick to the automobile's windshield. Mainly applied in vehicle management, vehicle charges, auto glass retail management and so on.
Various designs, color are all available to customize. Provide Logo printing according to customer's request.
The double composite windshield label can be printed on double sides according to customer's request.
Please learn more about the RFID parking system
It has good performance if work with the UHF RFID reader
Primary Applications:
- Parking
- Vehicle Management
- Vehicle Charge
- Auto Glass Retail Management
- E-payment
Specification
| Tag Size | 110X40mm (±0.5mm) |
|---|---|
| Chip IC | Alien H3, Impinj Monza 4QT (M4E, M4D, etc.) |
| Read Range | ≥6M (Fixed Reader) |
| Substrate Material | Polyester Film (PET) |
| Antenna Material | Aluminum Etching |
| Surface Material | Coated Paper, Fragile Paper, Waterproof PET, etc. |
| Open Frequency | 860MHZ~960MHZ |
| Protocol | ISO 18000-6C |
| Colours | White, Clear, or customised |
| Programming Cycle | 100,000 cycles |
| Applications | Parking, Vehicle Management, Vehicle Charge, Auto Glass Retail Management, etc. |
| Attribute | Disposable, Prevent Heat Transfer |
| Operating Temperature | -25℃~75℃ |
| Storage Temperature | 0℃~25℃ |
| Volume Number | 2000~3000PCS (According to Actual Demand) |
| Packing Material | Anti-static PE + Bubble Pad + Anti-static Bag |
